Electric Vehicles Explained: Charging, Range, and What to Look For

This electric vehicle guide explains how EVs are transforming driving with advanced features, efficient energy use, and smart charging. From range and battery capacity to charging levels and ownership tips, understanding EV basics helps you make the best decision for your lifestyle and budget.

Miles per kWh: The EV Equivalent of MPG

Most EVs achieve an efficiency of around 3 to 4 miles per kilowatt-hour (mi/kWh), meaning that for every kilowatt-hour of electricity consumed, the vehicle can travel approximately three to four miles. A higher mi/kWh rating indicates better energy efficiency, meaning the vehicle can travel farther on the same amount of electricity.

What is a good mi/kWh:

A good mi/kWh rating depends on several factors, including vehicle size, driving conditions, and driving habits. Generally:

• Compact and efficient EVs (e.g., Tesla Model 3, Hyundai Ioniq 6): Around 4 to 5 mi/kWh, considered very efficient.
• Mid-size and luxury EVs (e.g., Ford Mustang Mach-E, Tesla Model Y): Around 3 to 4 mi/kWh, providing a good balance of range and performance.
• Larger SUVs and trucks (e.g., Rivian R1T, Ford F-150 Lightning): Around 2 to 3 mi/kWh, due to their larger size and higher weight.

Factors like highway speeds, cold weather, and aggressive driving can reduce efficiency, while city driving and regenerative braking can improve it.

How does it compare to MPG: For a rough comparison, consider that 1 gallon of gasoline contains about 33.7 kWh of energy. If your EV gets 3 mi/kWh, it’s roughly equivalent to a gas car getting 101 MPG. This efficiency makes EVs more cost-effective in terms of fuel.

Battery Capacity, Range, and Energy Storage

Battery Capacity:

An EV’s battery capacity, measured in kilowatt-hours (kWh), determines how much energy it can store. Larger batteries generally provide more range but may take longer to charge.  For example, a 60 kWh battery might deliver a range of 200–250 miles, depending on the car’s efficiency and driving conditions.

Range:

This varies widely between models. Compact EVs typically offer shorter ranges, while luxury or long-range models can exceed 300 miles per charge.

Energy Efficiency (mi/kWh):

Vehicles with higher mi/kWh ratings use less energy to travel farther, making them more economical and environmentally friendly.

Charging Levels and Rates

Charging an EV depends on the type of charger and the vehicle’s maximum charging rate. Here’s what you need to know:

Charging Levels

Level 1 Charging

• Uses a standard household outlet (120V).
• Adds 2–5 miles of range
• Suitable for overnight charging but may be too slow for long commutes.

Level 2 Charging

• Requires a 240V outlet, commonly used for dryers.
• Adds 10–60 miles of range per hour.
• Ideal for home or public charging.  The typical rating for at home level 2 chargers is between 7.2 to 9.6 kW.

DC Fast Charging

• Found at highway rest stops and commercial locations.
• Adds 60–100 miles of range in about 20 minutes.
• However, frequent fast charging can wear down the battery over time.

The maximum charging speed of DC fast chargers can vary greatly depending on their power output, which is typically rated in kilowatts (kW) rather than volts or amps. Chargers can range from 50 kW to 350 kW, with higher-rated chargers delivering faster charging times. However, the actual charging speed depends on factors such as the EV’s onboard charging capacity, battery temperature, and state of charge.

Charging Rates: How Fast Can an EV Charge?

Charging an EV isn’t one-size-fits-all—charging rates depend on both the EV and the charger being used.

Understanding Charging Rates:

Charging rate is measured in kilowatts (kW), which indicates how much energy can be delivered to the battery per hour. The key specifications to look for are:

• Maximum Charging Rate of the EV: Or, how fast the car can accept energy. The charger is actually built into the EV. What most people call a “charger” is actually just the power source plugged into the car. The EV’s onboard charger determines how much power the battery can accept over time, while the power source’s output determines how much electricity is supplied. The charging rate is always limited by the lower of the two.

Example:

If an EV has an onboard charger rated at 11 kW but is plugged into a home charging station that provides only 7.2 kW, the charging speed will be limited to 7.2 kW. Conversely, if the power source can deliver 22 kW but the EV’s onboard charger is limited to 11 kW, charging will only occur at 11 kW.

• AC vs. DC Charging: EVs can charge using AC (Alternating Current) or DC (Direct Current) power. AC charging, such as Level 1 (120V) and Level 2 (240V) home or public stations, relies on the EV’s onboard charger to convert AC power into DC to store in the battery. This process is slower due to conversion limitations, typically maxing out at 7-11 kW, depending on the EV’s onboard charger capacity.

• DC fast charging: Commonly found at highway stations, bypasses the onboard charger and delivers power directly to the battery. Because the power is already in DC form, it allows much faster charging rates, often ranging from 50 kW to 350 kW, depending on the EV’s capability and the charger’s output. This makes DC charging ideal for rapid recharges on long trips.

• Charger Output: The power provided by the charger (power source). Here are a few examples to explain this process.  If an EV can accept 150 kW and you’re using a 150 kW DC fast charger, the car will charge at full speed. However, if the charger only delivers 50 kW, the charging rate will be limited to 50 kW, even if the car can handle more.  In another example, if you’re using a DC fast charger that can supply 300 kW, but your EV’s onboard charging system can only handle 150 kW, the car will charge at 150 kW, as this is its maximum capability. These examples show why it’s important to understand both your EV’s charging capabilities and the power output of the charging station you’re using.  It is useless to search for a 300kW DC charger if your car can only accept 150kW.

• Why Charging Slows After 80%: For battery health and efficiency, it is recommended to keep the batteries state of charge between 20-80%.  Charging from 20% to 80% is typically the fastest because EV batteries use a constant-current phase during this range, which maximizes charging speed. After 80%, it becomes increasing difficult for lithium ions to find available space which slows the charging process.  Throw in the car switches to a constant-voltage phase to protect the battery and ensure longevity. This process slows the charging significantly, which is why it’s often recommended to stop charging at 80% unless you need the full range.

Specifications to Look For in an EV

When choosing an EV, understanding key specifications can help you select the right car for your needs:

1.  Battery Capacity (kWh):

• Indicates how much energy the battery can store.
• Higher capacity means more range but also longer charging times.
• Common battery sizes range from 40-60 kWh in smaller EVs (e.g., Nissan Leaf, Hyundai Kona EV) to 75-100+ kWh in larger or high-performance models (e.g., Tesla Model Y, Ford Mustang Mach-E, Rivian R1T), with some long-range EVs exceeding 200 kWh (e.g., GMC Hummer EV).

2.  Range (Miles):

• How far the car can travel on a full charge.
• Look for EVs that meet your daily driving needs with some buffer for unexpected trips or other things like cold weather that can reduce driving range.

3.  Maximum Charging Rate (kW):

• Determines how fast the battery can charge when using a high-powered charger.
• Higher rates mean quicker charging times on road trips or at public charging stations.
• The maximum charging rate is largely influenced by the vehicle’s battery voltage system, typically either 400V or 800V. Vehicles with an 800V architecture, such as some high-performance EVs, can accept higher power levels and charge significantly faster compared to those with a 400V system. Understanding your EV’s voltage system can help you gauge its charging speed and compatibility with ultra-fast charging stations.

4.  Energy Efficiency (mi/kWh):

• Shows how effectively the car uses energy.

5.  Thermal Management Systems

• A Thermal Management System (TMS) regulates the temperature of an EV’s battery pack, power electronics, and electric motor to ensure optimal performance, longevity, and safety. EVs use active (liquid-cooled) or passive (air-cooled) systems to prevent overheating and minimize efficiency losses in extreme temperatures.
• Why It Matters: Proper temperature control improves battery lifespan, charging speed, and driving range, especially in hot or cold climates.

Key Takeaway: Liquid-cooled TMS is superior for long-term battery health and fast charging.

6. Battery Warranty Terms:

• An EV battery warranty covers defects and capacity loss over time, ensuring the battery retains a minimum level of performance for a specified period.
• Typical Coverage:
  1. 8 years / 100,000 miles (Industry standard, varies by manufacturer).
  2. Most warranties guarantee at least 70% battery capacity retention within the warranty period.

Key Takeaway: Check the degradation clause—some brands cover replacement only if capacity drops below 60-70%. If buying a used EV understand if the warranty is fully transferable and, if a CPO, how much if any additional coverage is added.

Special Features of EVs

EVs offer unique advantages that make them convenient and innovative:

Minimal Power Usage at Idle:

EVs use little energy when stationary, making them ideal for situations like sitting at a child’s sporting event. With the car on, you can stay warm in winter or cool in summer for hours without worrying about excessive energy use.

Vehicle-to-Load (V2L) Capabilities:

Some EVs can act as portable power stations, allowing you to charge household items or run appliances during power outages. This feature, often called vehicle-to-load (V2L), is perfect for camping trips or emergencies.

Instant Torque and Smooth Driving:

EVs deliver power directly to the wheels, providing instant acceleration and a smoother, quieter driving experience compared to gas-powered cars.

Low Maintenance:

EVs have fewer moving parts, reducing maintenance costs. There’s no oil to change, and brakes last longer due to regenerative braking systems.

Customizable Charging Times:

With smart charging, you can schedule your EV to charge during off-peak hours when electricity rates are lower, saving you money on energy costs.  You can also schedule your car to start before leaving for work, so it is warm/cool when you’re ready to leave.

Maximizing Battery Longevity

To ensure your EV battery lasts as long as possible:

Stay in the 20–80% Range:

Keeping the battery between these levels minimizes wear and extends its lifespan. Avoid charging to 100% or running it down to 0% frequently.

Limit DC Fast Charging:

Use fast chargers sparingly and rely on Level 2 chargers for daily needs.

Park Smart:

Protect your EV from extreme temperatures by parking in shaded or climate-controlled environments.

Follow Maintenance Guidelines:

Regular maintenance and software updates can improve battery management and efficiency.
